Titanium plate Sheet
Titanium Grade 7 Sheet Plate
Specifications
| Specifications | ASTM B265 / ASME SB265 |
| Grade | TA1 TA2 TA3 TC4 GR1 GR2 GR5 GR7 GR9 GR23 |
| Type | Shim Plate, Perforated Plate. |
| Thickness | 1mm to 200mm |
| Surface | Hot rolled plate (HR), Cold rolled Plate (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) |
| Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
Equivalent Grades
| NAME | WERKSTOFF NR. | UNS |
| Grade 7 | 3.7235 | R52400 |
Chemical Composition
| Grade | C | O | N | H | Fe | Pd |
| R52400 | 0.08 max | 0.25 max | 0.03 max | 0.015 max | 0.30 | 0.12-0.25 |
Mechanical Properties
| Grade | Tensile Strength minimum | Yield Strength | Elongation min, % | ||
| Gr.7 | ksi | MPa | ksi | MPa | |
| 50 | 345 | 40-65 | 275-450 | 20 | |
Features & Benefits
Titanium possesses outstanding corrosion resistance, able to withstand the corrosive effects of seawater, acids, and most chemical media.
Titanium rods exhibit an excellent strength-to-weight ratio, being one of the lightest structural materials.
Titanium is a biocompatible material, showing good compatibility with human tissues and bones.
Titanium exhibits excellent stability at high temperatures, maintaining strength and stability in high-temperature environments.
Titanium is a non-magnetic material, making it suitable for applications where magnetic sensitivity is a concern frequency operation.
Titanium has good formability, making it easy to process into various shapes.
Why Choose Us?
1.You can get the perfect material according to your requirement at the least possible price.
2. We also offer Reworks, FOB, CFR, CIF, and door to door delivery prices. We suggest you to do deal for shipping which will be quite economical.
3. The materials we provide are completely verifiable, right from raw material test certificate to the final dimensional statement. (Reports will show on requirement)
4. We guarantee to give a response within 24 hours (usually in the same hour)
5. Provide SGS TUV report.
6. We are fully dedicated to our customers. If it will not possible to meet your requirements after examining all options, we will not mislead you by making false promises which will create good customer relations.
7. Provide one-stop service.
Packing
1. Packing is quite important especially in a case of international shipments in which consignment pass through various channels to reach the ultimate destination, so we put special concern regarding packaging.
2. Saky Alloy’s pack our goods in numerous ways based on the products. We pack our products in multiple ways, such as.
